50 Taper, 60 ATC, Fanuc 15M
| size | 24.8" x 24.8" | 24.8" x 24.8" |
| X | 37" | 939.8 mm |
| Y | 32" | 812.8 mm |
| Z | 29" | 736.6 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 4,500 RPM | 4,500 RPM |
| Taper | 50 | 50 |
| Pallet-W | 24.8" | 629.92 mm |
| Pallet-L | 24.8" | 629.92 mm |
24.8" x 24.8" pallets KIA KH63G Horizontal Machining Center
Pallets (2): 24.8" x 24.8"
X Axis Travel: 37.4"
Y Axis Travel: 32.5"
Z Axis Travel: 29.9"
Rapid Rate X Axis: 787 IPM
Rapid Rate Y Axis: 787 IPM
Rapid Rate Z Axis: 787 IPM
Max Pallet Load: 2204 LBS
Spindle Speed: 4,500 RPM
Spindle Motor: 30 HP
50 Taper, 60 ATC, Fanuc 15M
