Lagun Lagunmatic VMC-3516, Dynapath Delta 40 CNC Control, 24"x16"x20", CAT40
| X-Axis | 24" | 609.6 mm |
| Y-Axis | 16" | 406.4 mm |
| Z-Axis | 20" | 508 mm |
| Power | 10 hp | 7.5 kW |
| RPM | 6,000 RPM | 6,000 RPM |
| # ATC | 18 | 18 |
| Taper | CAT40 | CAT40 |
| Table-W | 16" | 406.4 mm |
| Table-L | 35" | 889 mm |
| # Axis |
Lagun Lagunmatic VMC-3516
New: 1997
Specifications:
Table Size: 35” x 16”
Travels:
X-Axis: 24”
Y-Axis: 16”
Z-Axis: 20”
Table Load: 1500 Lbs
Spindle Nose-Table: 5.75-25.75”
Rapid Traverse Rate: 500 IPM
Spindle Taper: CAT40
Spindle Speed: 6000 RPM
Spindle Motor: 7.5/10HP
Tool Changer: 18 ATC
Equipped With:
Dynapath Delta 40 CNC Control
Torit Downflo Dust Collector
