2010 Kia KH63G Horizontal Machining Center - Fanuc 18i-MB Control, Full 4th Axis, 8,000 RPM, CAT-50 Spindle, 60 ATC, Through Spindle Coolant.
| X | 37.4" | 949.96 mm |
| Y | 32.5" | 825.5 mm |
| Z | 29.9" | 759.46 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 8,000 RPM | 8,000 RPM |
| # ATC | 60 | 60 |
| Taper | CAT-50 | CAT-50 |
| Pallet-W | 24.8" | 629.92 mm |
| Pallet-L | 24.8" | 629.92 mm |
| # Axis | 4 | 4 |
| Control | CNC (Fanuc 18i-MB) | CNC (Fanuc 18i-MB) |
| Weight | 30,100 LBS | 30,100 LBS |
Pallet Size.......................24.8" x 24.8""
Max Pallet Load...................2,204 LBS
Pallet Indexing...................0.001"
X-Axis Travel.....................37.4"
Y-Axis Travel.....................32.5"
Z-Axis Travel.....................29.9"
Spindle Motor.....................30 HP
Spindle Taper.....................CAT-50
Spindle Speed.....................8,000 RPM
Tool Changer......................60 ATC
Machine Dimensions................216" x 132" x 126"
Print Dimensions..................184"L x 110"W x 105" With Work Light Removed from Top
Chip Conveyor & Coolant Tank......116" x 42" x 114"
Weight............................30,100 LBS
Fanuc Series 18i-MB Control
8,000 RPM CAT-50 Spindle
Full 4th Axis
60 Tools
Thru-Spindle Coolant
Chip Conveyor
**BUYER RESPONSIBLE FOR VERIFYING SPECIFICATIONS & OPTIONS**
