HAAS EC-300 CNC Horizontal Machining Center 2009, model EC-300, serial 2052895. Features 20" X axis, 18" Y axis, 14" Z axis travel, CAT-40 taper spindle up to 12,000 RPM, 24-tool changer, B axis 360,000 position. Includes Haas CNC control, pallet changer, and chip conveyor.
| Dimensions | 130” L x 122” W x 102’’ H | 130” L x 122” W x 102’’ H |
| Weight | 16,000 Lbs. | 16,000 Lbs. |
Reference # 6030
Model # : EC-300
Serial # : 2052895
Year of manufacture: 05/2009’
Pallet size: 11.8” x 11.8”
Maximum pallet weight: 550 Lbs.
X axis travel: 20"
Y axis travel: 18"
Z axis travel: 14"
B axis: 360,000 Position
Spindle speeds: up to 12,000 R.P.M.
Spindle taper: CAT-40
Tool changer capacity: 24 tool
Haas CNC control with USB emulator and MPG Remote Job Handle
Control options- Rigid Tapping, Programmable Coolant Nozzle, DNC, Quick Code, Advanced tool management Wired for 4th & 5th Axis (5th axis is secondary pallet B axis)
Machine hours
Pallet changer
Coolant tank and pump
Henig Chip conveyor
Machine is wired for 230 volt / 3 phase / 60 H.Z.
