Marvel/Spartan S330/2HV Horizontal Mitering Bandsaw
Spartan by Marvel Horizontal Miter bandsaw. 60 degree miter capability, Like Hyd-Mech, Hem Amada
| Rect-Cap (H) | 12" | 304.8 mm |
| Rect-Cap (W) | 18" | 457.2 mm |
| Rounds-Cap | 13" | 330.2 mm |
| Square-Cap | 12" | 304.8 mm |
| Power | 3 hp | 2.2 kW |
| Type (Auto, Manual, Semi) | Semi | Semi |
| Blade Width | 1" | 25.4 mm |
| Blade Thickness | 0.035" | 0.889 mm |
| Blade Length | 162" | 4,114.8 mm |
| Dimensions | 87" x 83" x 54" High | 87" x 83" x 54" High |
| Weight | 2,200 lbs. | 2,200 lbs. |
Capacity: Nominal 12" x 18"
Maximum 13" Round
Blade at 45 degrees (Nominal) 11"H x 12"W
Blade at 60 Degrees(Maximum) 11"H x 8" W
Length 13, 6"
Width/ Gauge 1" x .035
Working height 30.5"
Roller Extension Table 5'
Blade tension 30,000 psi
Vise: Open (Max.) 18"
Height of Jaw 6.5"
Drive: 3 HP, 1800 RPM TEFC Motor
Blade Speeds 0-330 FPM
Machine Dimensions 87" x 83" x 54" High
Shipping Weight 2,200 lbs.
Eagle beak VTR blade 3/6 tooth pitch $51.00
Variable vise pressure $1,490.00
Auto mist lube $2,370.00
Free Standing ROLLER table 5' long $1,250.00
230 volt/ 3phase No Charge
208 Volt/ 3 phase $1,645.00
Note Buy 20 or more blades with initial saw purchase extra year parts warranty
Inverter drive for Blade speed 0-330 FPM, Hydraulic downfeed, Hydraulic frame return lifts up head with the push of a button, Hydraulic Vise clamp, Carbide Blade guides, 1' blade, Chip brush, Coolant systen, Swivel -60 degrees to +45 degrees with Scale and pointer, 110 volt contraol and all available manuals
