BERTHIEZ TVM 125 CNC Vertical Boring Mill with live milling, used and built in 1997. Features 62" table, 75" max swing, 31.5" machining height, 125 HP spindle, Fanuc 15TB CNC control, 20 position tool changer. Includes loading. Contact for pricing.
| Capacity | 63" | 1,600.2 mm |
| Control | CNC (FANUC 15) | CNC (FANUC 15) |
BERTHIEZ TVM 125
CNC VERTICAL BORING MILL WITH LIVE MILLING
TABLE DIAMETER.......................... 62"
MAXIMUM SWING........................... 75"
HEIGHT UNDER RAIL....................... 43.3"
MAXIMUM MACHINING HEIGHT................ 31.5"
VERTICAL TRAVEL OF RAM.................. 31.5"
TABLE SPEEDS............................ 3.2 TO 400 RPM
SPINDLE DRIVE MOTOR..................... 125 HP
MAXIMUM PART WEIGHT..................... 22,000 LBS
FEED RATE X & Z......................... 0.004 TO 78.7 IPM
RAPID TRAVERSE X & Z.................... 472 IPM
C-AXIS INDEXING......................... 0.001 DEGREES (360,000 POSITIONS)
C-AXIS TRAVERSE......................... 5 RPM
LIVE MILL SPEEDS........................ TO 2,000 RPM
LIVE MILL MOTOR......................... 11 HP
* FANUC 15TB CNC CONTROL
* 20 POSITION AUTOMATIC TOOL CHANGER
* COOLANT THROUGH SPINDLE
* 62" FACE PLATE WITH 4-JAWS
* (APPROXIMATE 15 TOOL BLOCKS)
* TOOL AND PART PROBES
* CHIP CONVEYOR AND FULL ENCLOSURE
PRICE INCLUDES LOADING - MACHINE RUNS GREAT
Time to let this machine sell, will consider a reasonable offer. CALL TO DISCUSS PRICING
