| Swing | 19.69" | 500.13 mm |
| Machining Length | 17.72" | 450.09 mm |
| Chuck Size | 6" | 152.4 mm |
| Bar Capacity | 2.01" | 51.054 mm |
| Power | 20 hp | 14.9 kW |
| Max RPM | 6,000 RPM | 6,000 RPM |
| Turning Dia | 11.81" | 299.97 mm |
| Tailstock | No | No |
| Dimensions | 153" x 62" x 75" | 153" x 62" x 75" |
| Weight | 9,000 Lbs | 9,000 Lbs |
SWING OVER BED ................. 15.74"
SWING OVER CROSS SLIDE ......... 11.81"
MAX. TURNING DIAMETER .......... 9.68"
DISTANCE BETWEEN CENTERS ....... 23.6"
BAR CAPACITY ................... 1.96"
X-AXIS TRAVEL .................. 8.26"
Z-AXIS TRAVEL .................. 17.71"
MAX. SPINDLE SPEED ............. 6000 RPM
SPINDLE POWER .................. 16kW
TAILSTOCK TRAVEL ............... 15.74"
TURRET TYPE .................... SAUTER 05.456.416
NUMBER OF TOOLS ................ 12 (ALL STATIONS DRIVEN)
TOOL SYSTEM .................... VDI 30 (AXIAL)
DRIVEN TOOLS SPEED ............. 5000 RPM
C-AXIS INDEXING ................ 0.001 DEGREE
APPROX. DIMENSIONS ............. 153" X 62" X 75"
APPROX. WEIGHT ................. 9,000 LBS
Fanuc 180i TB cnc control with 15" TFT Screen, 3D Graphics, Manual Guide i Software
- C& Y AXES
- 8" SMW HYD. CHUCK
- 12 POSITION TURRET
- TAILSTOCK
- CHIP CONVEYOR
- LIVE TOOLHOLDERS
- ALL AVAILABLE STANDARD TOOLHOLDERS
- ALL AVAILABLE MANUALS
