| Tonnage | 130 T | 117.934 t |
| Type | HYD | HYD |
| Overall Length | 10' | 3 m |
| Between Housings | 100" | 2.5 m |
| Stroke | 8" | 203.2 mm |
| # Axis | 5 | 5 |
| Control | CNC (Accurpress) | CNC (Accurpress) |
| Dimensions | 143″ L x 53″ W x 96″ High | 143″ L x 53″ W x 96″ High |
| Weight | 15,000 Ibs Approx. | 15,000 Ibs Approx. |
*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
Specifications:
Capacity:
Tonnage: 130 Ton
Bed Length: 120″
Distance Between Housing:100″
Closed Height: 6″
Open Height: 14″
Stroke Length: 8″
Throat Depth: 10″
Approach Speed: 76 / 28 IPM
Return Speed: 160 IPM
General:
Power Source: AC 440 V, Three Phase, 60Hz
Overall Dimensions: 143″ L x 53″ W x 96″ High
Weight: 15,000 Ibs Approx.
Accurpress Control
Electric Foot Pedal
10′ Long Bed
Back Gauging
20 HP Motor
