| Tonnage | 138 T | 125.192 t |
| Type | HYD | HYD |
| # Axis | 3 | 3 |
| Bending Length | 161" | 4,089.4 mm |
| Table Width | 3.54" | 89.916 mm |
| Clear Pass | 137.8" | 3,500.1 mm |
| Ram Stroke | 11.8" | 299.72 mm |
| Open Height | 19.09" | 484.89 mm |
| Throat Depth | 15.75" | 400.05 mm |
| Approach/Pressing/Return Speed | 3.94/0.24/2.56 | 3.94/0.24/2.56 |
| Dimensions L x W x H | 177.17x82.68x118.11 | 177.17x82.68x118.11 |
| Weight | 23705 | 23705 |
ACCURACIES
• Press Beam Depth Accuracy: ± 0.01mm
• Press Beam Depth Repeatability: ± 0.01mm
• Back Gauge Accuracy: ± 0.1mm
• Back Gauge Repeatability: ± 0.1mm
• 3 Axis machine with automatic, accurate & fast back gauge
• CybTouch 8PS Controller from CYBELEC Switzerland
• Rigid upper beam guide on 12-point roller bearings
• Ultrasonically & tensile tested IS:2062 grade steel structure ensures the rigidity & avoid deflection.
• The frame is machined on Floor Boring Machine ensuring single reference accurate machining.
• Quick release clamps
• Back gauge assembly included ball screw, AC Servo drive, LM guides & timer belt
• Back gauge fingers mounted on LM guide
• Quick ‘V’ groove change over with self-centred die with rail.
• Hardened & grounded 2‘V’ / 4‘V’ die & semi gooseneck punch
• Front sliding sheet support with LM guides for easy movement
