6 Ton Denison R06, 6 station 21" dia. rotary table, 10" str., 16" DL, #29140
Tonnage | 6 T | 5.443 t |
Stroke | 10" | 254 mm |
Daylight | 8" | 203.2 mm |
IPM Closing | 165 in/min. | 419.1 cm/min. |
IPM Pressing | 165 in/min. | 419.1 cm/min. |
Bed (F-B) | 6" | 152.4 mm |
Bed (L-R) | 0" | 0 mm |
USED 6 TON DENISON HYDRAULIC ROTARY C-FRAME PRESS
Model no. R06MC209D266C220C235A12A59IT106R
Table model on factory stand
With model 106R, 6 station, 21" diameter rotary index table
Bed area: 17" L-R x 10.5" F-B with 5" U-slot
Stroke: 0 - 10" maximum
Daylight opening (total): 16" maximum
Daylight opening (index table
to ram): 8" maximum
Throat depth: 6"
Ram diameter: 2.75/2" @ 2020 PSI - 6 tons
Floor to top of rotary table: 37"
Power unit: Denison hydraulic pump, driven by
5 HP 1750 RPM 220/440/3/60 motor
Speeds approx.: 165"/minute closing
165"/minute pressing to 6 tons
460"/minute return
Controls: Pushbutton operation with stroke &
pressure control
Operator pushbutton for run & stop
Electric foot switch
Inching control
Pressure gauge
Weight approx. 1,900 lbs.
Overall dimensions approx. 32" L-R x 45" F-B x 68" H
Serial no. 19074
Stock no. 29140
FOB ELK GROVE VILLAGE, IL
