Swing | 20.1" | 510.54 mm |
Machining Length | 16.1" | 408.94 mm |
Chuck Size | 8" | 203.2 mm |
Bar Capacity | 2.99" | 75.946 mm |
Power | 20 hp | 14.9 kW |
Max RPM | 4,500 RPM | 4,500 RPM |
Turning Dia | 13.4" | 340.36 mm |
Tailstock | Yes | Yes |
Dimensions | 105″ x 64″ x 69″ | 105″ x 64″ x 69″ |
Weight | 8800 lbs | 8800 lbs |
General:
Power: 220v / 3-Phase
Overall Dimensions: 105″ x 64″ x 69″ High
Overall Dimensions: 130″ x 64″ x 69″ High (With Chip Conveyor)
Weight: 8800 lbs
X Axis Travel: 9.53″
Z Axis Travel: 17.32″
Rapid Traverse X Axis: 787 IPM
Rapid Traverse Z Axis: 1000 IPM
Spindle Nose: A2-6
Spindle Motor: 11/15 kw
Turret Capacity: 12 Stations
Turret Index Time: 0.5 Second
Tailstock Taper: MT-4
Tailstock Quill Dia.: 2.95″
Tailstock Quill Travel: 3.15″
8″ 3 Jaw Hydraulic Chuck
Tool Presetter
Hydraulic Tailstock
Coolant System
Barfeed Interface
RS-232 ports
12 Station Automatic Turret
Chip Conveyor
Comes w/ Mitsubishi Controls
