- PREOWNED JOHNFORD 3 AXIS CNC TURNING CENTER, MODEL #: SL-500-CS, S/N: TEN130147, YEAR: 2013
| Swing | 22.8" | 579.12 mm |
| Machining Length | 17.7" | 449.58 mm |
| # Axis | 3 | 3 |
| Chuck Size | 10" | 254 mm |
| Bar Capacity | 3" | 76.2 mm |
| Power | 25 hp | 18.6 kW |
| Max RPM | 3,500 RPM | 3,500 RPM |
| Tailstock | Yes | Yes |
| Control | CNC (FANUC 0i-TC) | CNC (FANUC 0i-TC) |
| Weight | 15500 | 15500 |
Specs
Swing Over Bed 22.8 inches
Swing Over Cross Slide 17.7 inches
Center Distance 31 inches
Bar Capacity 3 inches
Rapid Traverse Z 944 IPM
Rapid Traverse X 787 IPM
Z-Axis Travel 675.4 inches
X-Axis Travel 11.5 inches
Chuck Size 10 inches
Spindle Nose A2-8
Spindle Speed 3,500 RPM
Spindle Motor 25 HP
Turret Capacity 12
Tailstock Travel 23.6 inches
Quill Travel 3.93 inches
Machine Weight 15500 pounds
* Fanuc 01-TB CNC Control
* C-Axis
* Live Tooling
* Tool Presetter
* Tailstock
* Parts Catcher
