Bending Force 66 Tons
Max. Bending Length 60”
Max. Stroke 8.6"
Max. Daylight (Open Height without Tools) 17.3”
Approach Speed 6.8 IPS
Bending Speed 0.4 IPS
Return Speed 6.8 IPS
Travel in X-Axis (Standard) 15.7"
Main Motor 5 hp
Voltage 480Volt 3-Phase
Length 108”
Width 69”
Height 104”
Weight Approx. 8,267 lbs.
Y1, Y2, X=400mm Included
Control Unit – Cybelec 12PS 2D Graphical Autobend Sequence
European Clamping system
Back gauge : X,R Ballscrew system
Back Gauge Fingers – Height Adjustable
Rear Light
Safety Covers
Working Table
Wilson Quick Clamps
