The jC Series high-performance vertical machining centers deliver top-end quality and excellent value. Every machine tool is built and handcrafted for rigidity, thermal stability, and repeatability. The jC Series produces consistent high-quality results from the first part to the last.
| X | 50" | 1,270 mm |
| Y | 25.9" | 657.86 mm |
| Z | 24.4" | 619.76 mm |
| Power | 25 hp | 18.6 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 30 | 30 |
| Taper | Dual Contact CAT-40 / BBT-40 | Dual Contact CAT-40 / BBT-40 |
| Table-W | 53.1" | 1,348.7 mm |
| Table-L | 26" | 660.4 mm |
| # Axis | 3 | 3 |
300 PSI Through Spindle Coolant System (CTS)
