| Table-W | 39.37" | 1,000 mm |
| Table-L | 110.24" | 2,800.1 mm |
| # Axis | 5 | 5 |
| Travel-Long | 98.43" | 2,500.1 mm |
| Travel-Cross | 39.37" | 1,000 mm |
| Power | 29.5 hp | 22 kW |
| RPM | 4,000 RPM | 4,000 RPM |
| Taper | ISO 50 | ISO 50 |
| Weight | 48,500 lbs | 48,500 lbs |
Specifications (subject to buyer verification):
Table Surface: 149.6” x 36.37”
T-Slots: 0.19” x 0.86”
Distance between T Slots: 7.87”
Max weight allowed on table: 17,636 lbs
Longitudinal Traverse (X Axis): 137.8”
Cross Traverse (Y Axis): 39.37”
Vertical Traverse (Z Axis): 39.37”
Working Feeds (X/Y/Z): 5-7,000 mm/min
Rapid Traverse: 20,000 mm/min
Auto-Indexing Head UAD: 0.1º/ 0.1º
Taper: ISO 50 DIN 69871
Turning Speeds: 6,000 RPM
Speed Ranges: 2
Head Power: 29.5 HP
ATC Positions: 30
Machine Weight: 48,500 lbs
Equipped With (subject to buyer verification):
Heidenhain TNC-430 CNC Control
Heidenhain HR-410 Electronic Handwheel
Internal coolant
4th Axis Rotary Table
Tailstock
Chip Conveyor
Full Guarding
