| X | 1,050 mm | 41.339" |
| Y | 500 mm | 19.685" |
| Z | 530 mm | 20.866" |
| RPM | 8,000 RPM | 8,000 RPM |
| # ATC | 24 | 24 |
| Taper | 7/24 Taper No.40 | 7/24 Taper No.40 |
| Table-W | 500 mm | 19.685" |
| Table-L | 1,100 mm | 43.307" |
| Control | CNC (Fanuc 0I-MD CNC Control) | CNC (Fanuc 0I-MD CNC Control) |
| Dimensions | 79” x 113” | 79” x 113” |
Specifications (subject to buyer verification):
Distance Between Spindle Nose to Table: 24.8” Maximum, 4” Minimum
Longitudinal Travel X: 41.3”
Vertical Travel Z: 20.87”
Cross Travel (Table): 19.68”
Table Size: 42.8” x 19.4”
Maximum Table Load: 1,100 lbs
Spindle Taper: BT40
Spindle Speed: 60 – 8,000 RPM
Rapid Traverse: X & Y: 30 m/min
Rapid Traverse Z: 24 m/min
Tool Quantity: 24
Maximum Tool Diameter: 3.5”
Maximum Tool Length: 9.84”
Maximum Tool Weight: 15 lbs
Position: 0.01 mm/Full Travel
Repeatability: +/- 0.005 mm
Electrical: 220V, 3 Ph, 75 Amps
Floor Space: 79” x 113”
Equipped With (subject to buyer verification):
FANUC Series 0i-MD Control
