| Swing | 32" | 812.8 mm |
| Centers | 120" | 3,048 mm |
| Spindle Bore | 5" | 127 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 500 RPM | 500 RPM |
| Swing Over Cross Slide | 22" | 558.8 mm |
| Dimensions | 200” x 66” x 72” | 200” x 66” x 72” |
| Weight | 12,650 lbs | 12,650 lbs |
Specifications (subject to buyer verification):
Swing: 32”
Swing over the Cross Slide: 22”
Swing over the wings of saddle: 29.25"
Swing in the gap: 43"
Distance between Centers: 120”
Cross slide travel: 19.5"
Top slide travel: 8"
Spindle nose: ASA A1-15
Spindle bore: 4.25”
Taper in reduction sleeve: MT-6
Spindle speeds: 18
Speeds range: 6.3 - 500 RPM
Threads number: 96
Metric threads (16): 0.6/8 mm
Inch threads (32): 44/3 TPI
Module threads (16): 0.375 / 5 Mod
Diametral pith threads (32): 6 / 88DP
Enlarged pitch threads system: 8:1
Longitudinal feeds (64) IN / Rev: 0.0034 / .0740
Cross feeds: (64) IN / Rev: 0.0017 / .0370
Enlarged feeds system: 8:1
Longitudinal rapid feed: 102 IN/Min
Cross rapid feed: 51 IN / Min
Main motor: 30 HP
Rapid traverse: 1.5 HP
Coolant unit motor: 1/8 HP
220 Volt/ 60 Hz/ Phase 3
Dimensions: 200” x 66” x 72”
Weight: 12,650 lbs
Equipped With (subject to buyer verification):
Steady Rest
Quick Change Toolpost
Tail Stock
Digital Readout
