Features
3 HP AC-Freq drive head with digital spindle RPM display and load meter. Automatic spindle direction reversal when switching between high and low speed gear ranges
12” x 50” hardened and ground table top
60-550-4500 spindle RPM (Hi/Low gear)
Automatic centralized lubrication system with metered check-valves
Single-phase or 3-phase power without the need for a phase converter
Hardened and Ground (Hrc-52) table surface and all slide ways
Solid box ways on saddle and column
Easy conversational programming, DRO-mode allows for full manual operations with built-in 3 axis absolute encoder glass scales
Engraving feature and DXF file import capability, USB drive and 12.1” high resolution flat panel color LCD display
Table Size 12" x 50"
Table Travel (X-Axis) 30"
Saddle Travel (Y-Axis) 17"
Knee Travel (Z-Axis) 17.25"
Quill Travel 4"
Ram Travel 22"
Spindle Motor 3 HP
Spindle Speed AC Frequency Drive Head 60-550-4500 RPM
Spindle Taper R-8
Quill Diameter 3.375"
Quill Feed Rate 0.0015" / 0.003" / 0.006" in/rev
Drilling Capacity (Manual / Power) 0.75" / 0.37" diameter
Boring Capacity 6" diameter
Milling Capacity 2.0 in³/min
Maximum Work Load (Center) 850 lbs
Spindle Center to Column 5" - 27"
Net Weight 3400 lbs
Gross Weight 3600 lbs
Shipping Dimensions 72" x 72" (skid)
Power Requirements 220V 3-phase or 1-phase for machine, 10A (15A for 1-phase); Optional 440V requires 3-phase, 7.5A 110V dedicated for CNC control, 20A
Optional Accessories
Knee (Z-Axis) Power Feed
Air Power Drawbar
Flood Coolant System
Chip Pan
Riser Block
Angle-Lock Vise
Rustlick Coolant
