NEW 2024 CHICAGO DREIS & KRUMP HS 4165

Overview
Model:
HS 4165
Year:
2024
Stock #:
21609
Status:
For Sale
Description

CHICAGO DREIS & KRUMP Model HS 4165 Hydraulic Shear 1/4" x 161" Capacity
Chicago Dreis & Krump began servicing the metalworking industry in 1899. Many things have changed since 1899, but Dreis & Krump has never wavered from supplying quality machines to the metalworking industry. Whether you need a heavy duty plate shear for that really big job, or a sheet metal shear for medium duty work – Dreis & Krump has got you covered. Now you can get your choice of the best hydraulic shears on the market, hydraulically driven for quiet, dependable operation and increased productivity, at a price you can easily afford.
Chicago Dreis & Krump offers machines such as: * sheet metal hand brakes * sheet metal box & pan finger brakes * hydraulic press brakes * hydraulic shears * hydraulic powered leaf brakes * electric powered leaf brakes * slip rolls and plate rolling machines. * The parts department has been known to provide user assistance for machines exceeding 60 years of age. we hope that you ask yourself, who will be around when you need help? Blackout Equipment LLC is Chicago-based and ready to help you with any Chicago Dreis & Krump sheet metal working machinery.

Specifications
Max Thickness0.25"6.35 mm
Length of Blade161"4.1 m
Hyd/MechHydHyd
Back Gauge31.5"800.1 mm
Power15 hp11.2 kW
SPM16 strokes/min.16 strokes/min.
ControlCNC (NC Control)CNC (NC Control)
Weight24,000 lbs24,000 lbs

Max Thickness 0.25"
Length of Blade 161"
Hyd/Mech Hyd
Back Gauge 31.5"
Power 15 HP
SPM 16 strokes/min.
Hold Downs 18
Table Height 32"
Weight 24,000 LBS

Equipped With

All steel welded construction *
Swing beam design *
Hydraulic hold-downs with nylon pads *
Blade gap adjustment *
Electric foot switch *
Electronic stroke counter *
Numerically Controlled power operated back gauge *
Length of stroke control *
Unitized hydraulic manifold *
Front gauge / support arms with scales and flip stops *
Squaring arm with scale *
Back gauge retract *
Ball supports *
Shadow line *
1°30' Cutting Angle *
49" Front Gauge *
31.5" Back Gauge
