80,000 / 100,000 LB. BRISTOL RIGGER SPECIAL FORK LIFT
MFG: Bristol
MODEL 80-100
MFG: 2001
80,000 Lb. At 24” Load Center Counter Weight Retracted
100,000 Lb. At 24” Load Center Counter Weight Extended
Hydraulic Boom With Stand, Max. Lift Height 22’ 6”
8’ 6” Max. Lift Height Forks
102” Min. Height to Top of “A” Frame
98” Fork Spread & Length
74” Thread Width, Drive Axle
101.” Width Over Tires
99” Height to Top of Carriage
37” Steer Axle CL to Rear of Counter Weight
4” Clearance Under Mast
199” Overall Length, Less Forks
235” Overall Length With Hydraulic C.W. Ext.
100 - 10 Tires
196” Outside Turn Radius (Tail Swing)
460 Ford Propane Engine (LP)
For Hydraulic Sliding Counter Weight, Add 8,000 Lbs.
Weight: 78,000 Lbs.
