2014 Muratec MW-80 GT Twin Spindle with Twin Gantry Loaders Feature Super High-Speed Processing with for high-speed processing of parts up to 80mm ( 3.14") in diameter for Shorter Cycle Times With its high-speed gantry, fast load/unload times, and reduced cycle times, the MW80 delivers shorter cycle times Flexible Machining!. Full Operation HD Videos and New Work area Views in Process!
| Swing | 7" | 177.8 mm |
| # Axis | 2 | 2 |
| Chuck Size | 6" | 152.4 mm |
| Power | 10 hp | 7.5 kW |
| Max RPM | 6,000 RPM | 6,000 RPM |
| Turning Dia | 6" | 152.4 mm |
| Tailstock | No | No |
| Live Tooling | No | No |
| Sub Spindle | No | No |
| Control | CNC (Fanuc 31iTB) | CNC (Fanuc 31iTB) |
| Weight | 8,810 Lbs. | 8,810 Lbs. |
The Muratec MW-80 GT Twin Spindle Twin Gantry Loaders
Feature Super High-Speed Processing with a twin gantry Loaders
for high-speed processing of parts up to 80mm ( 3.14") Standard
in diameter for Shorter Cycle Times With its high-speed gantry, fast load
/unload times, and reduced cycle times, the MW80 delivers shorter cycle times
The Muratec MW-80-GT is incredibly flexible and has a wide gang tool platform for added versatility and ability Special Secondary High Speed Milling Units Can Be Added for Electric High Torque or Air driven Mill-Drill or Grinder Finish Turning Yuasa or Technara High RPM 30k 80k Spindles.
2014 MURATEC MW-80 Twin Spindle - Twin Gantry Loaders Machine Specs & Technical Data!. Maximum Chuck Size 6" 3-Jaw Standard CNC Collet Chucks on Stock Machine Installed. Number of Turret Stations Tool Plate x 2, Width: 14.57 in
Maximum Spindle Speed 6000 rpm
Spindle Drive Motor 7.5 kW /30 min 10 Hp.
Total Machine Weight (Approx.) 8818 Lbs.
Gantry Loader Work piece Handling Capacity
Φ80 mm x 50 mm , up to 0.5kg/piece
Spindle Nose Size Flat nose
Spec. of Axes X-axis 18 m/min | Z-axis 18 m/min
Special in Plant Under Power Pricing in Process an on Request.
Please Email Request.
Thank You!
Sincerely,
Mark Murphy
