TAKUMI, V32, CNC VERTICAL MACHINING CENTRE, 10,000 RPM SPINDLE, TRAVELS (X,Y,Z): 3200 MM X 1066MM X 750 MM (126" X 42" X 30), DISTANCE FROM NOSE TO SPINDLE: 200MM TO 950MM, DISTANCE FROM SPINDLE NOSE TO THE Z-AXIS GUIDEWAY: 1120MM, T-SLOT TABLE SIZE: 3200MM X 1025MM (126" X 40"), MAX TABLE LOAD, 4500 KG (9,920 LBS), 32 TOOL ATC, TABLE SIZE: 42" X 130", CAT 50, 30 KW, SPINDLE FLOOD AND THROUGH COOLANT, AIR BLAST, COOLANT FILTER SYSTEM, CHIP WASH DOWN SYSTEM, CHILLED BALL SCREW AND SPINDLE, 4-AXIS CAPABLE, LEFT AND RIGHT CHIP CONVEYOR, 2 SPEED, LOW/HIGH GEARBOX, MITSUBISHI, MEDLAS 60S, CNC CONTROL, 2006, 220/3/60 50 AMP, MACHINE WEIGHT: 52.500 LBS. FLOOR SPACE (W, L, H) 295" X 173" X 139.7" (APPROX.),S/N K0133
| X | 126" | 3,200.4 mm |
| Y | 40" | 1,016 mm |
| Z | 30" | 762 mm |
| Power | 35 hp | 26.1 kW |
| RPM | 10,000 RPM | 10,000 RPM |
| # ATC | 30 | 30 |
| Taper | 50 | 50 |
| Table-W | 40.35" | 1,024.9 mm |
| Table-L | 126" | 3,200.4 mm |
| # Axis | 4 | 4 |
