| Capacity | 34" | 863.6 mm |
| Max Dia. Hole Drilled | 0.75" | 19.05 mm |
| Max Drilling Depth | 15" | 381 mm |
| # Spindles | 1 spdl | 1 spdl |
| Dimensions | 36" x 70" | 36" x 70" |
| Weight | 5,500# | 5,500# |
Specifications:
Drilling Capacity: .055-3/4"
Maximum Swing: 16"
Maximum Depth Drilled: 15"
Maximum Drill Speed: 11
Center Line of Spindle to Top of Table: 8"
Spindle Travel, Ball Screw Feed: 18 1/2"
Maximum Diameter Drill: 3/4" Mild Steel
Maximum Diameter Drill: 1" Aluminum or Equal
Floor Space: 36" x 70"
Approximate Weight: 5,500 lbs
FOB: Loaded on Truck
T-Slot Table 20" x 68"
3 HP Drill Drive Motor
1/2 HPD Feed (Ball Screw Drive) Motor
High Pressure Pump 10 HP
Mega Flow High Pressure Coolant System
Coolant Pump
Part Counter And Tool Counter
Fan Motor for Cooling
2 Filters
Cabinet Enclosure - 36" x 70"
208/230/-480/60 Electrics
