15" X 71" Used WMW Heckert Horizontal Milling Machine With Independent Universal Vertical Head
| Table Size-W | 15" | 381 mm |
| Table Size-L | 71" | 1,803.4 mm |
| Power | 15 hp | 11.2 kW |
| Dimensions | R-L 96" X F-B 96" X Height 96" | R-L 96" X F-B 96" X Height 96" |
Table Size.........................................15" X 71"
Table Load.........................................3,300 Lbs.
Table Travel.......................................44.1"
Table Cross Travel.................................13.6"
Table Swivels Right & Left Of Center...............45 Degrees
Spindle Taper......................................50"
Knee Travel Up & Down..............................21.6"
Distance Vertical Spindle To Table Min / Max.......1" To 14"
Spindle Speeds.....................................45 To 2,240 Rpm's
Spindle Speed Vertical Head........................28 To 1,400 Rpm's
Spindle Taper Both Horizontal And Vertical.........#50
Saddle And Table Feeds.............................3/8 To 90 I.P.M.
Rapids Long. & Cross...............................124 I.P.M.
Rapids Knee........................................40 I.P.M.
Main Motor.........................................15 Hp.
Main Motor Vertical Head...........................5 Hp.
Machine Floor Space................................R-L 96" X F-B 96"
Height.............................................96"
Weight.............................................9,600 Lbs.
Power Draw Bar On Horizontal Spindle...............Yes
Double Swivel Vertical Head........................Yes
Coolant............................................Yes
Pendent............................................Yes
Wide Knee..........................................Yes
Arbor Supports.....................................(2) Yes
Note: Clean has been cleaned, painted and cycled.
Machine came of of a Nevada power plant.
