NEW MORRISON 1-1/4

New Morrison Model K 1-1/4" Mechanical Keyseater
1 ¼" Morrison Keyseater includes: 2 HP- 60 Hz, 220/440 VAC Motor, New VFD Speed Control, One Shot Lubrication, Centering Vee, Swing Bar clamp, Cutter Bar support, Automatic Table Feed and Stop, Two (2) Tee slots 4" from Center.

Table Size....................................24" X 27"
Table Height From Floor.......................36"
Table Tee Slots...............................4" From Center
Cuts Key Ways.................................1/16" To 1-1/4"
Maximum Length Of Key Ways....................9"
Strokes Per Minute............................Adjustable 15 To 40
Number Of Feed................................0.002, 0.004 & 0.006
Largest Diameter Of Cutter Bar................1-1/4"
Distance From 1' Cutter To Column.............16-1/4"
Maximum Distance Under Standard Clamp.........25-1/2"
Main Motor....................................2 Hp.
Floor Space...................................36" X 48" X 54" High
Shipping Weight...............................1,400 Lbs.
Automatic Table Stops.........................2
Standard Equipment Included.
2 Hp 60 Hz. 240 / 480VAC Motor................Yes
Heavy Duty Variable Frequency Drive...........Yes
Centering Vee And Holding Clamp Bar...........Yes
Crating charge for all machines...............$250.00 Included In Price

Options Not Include In Price:
Prices Subject To Change Without Notice:
1/4" Cutter Bar Max. length Of Keyway in
5-1/2" From Table.............................$535.95
3/4" Cutter Bar Max. length Of Keyway in
6-1/2" From Table.............................$572.31
1" Cutter Bar Max. length Of Keyway in
9" From Table.................................$582.25
1-1/4" Cutter Bar Max. length Of Keyway in
9" From Table.................................$590.63
Special Cutter Bar For 14" Keyway.............$811.68
Special Broaching Packing.....................$979.35
Taper Attachment..............................$2,901.70
Kool Guard Light..............................$148.00
