450HC GLEASON/PHOENIX CNC DRY CUTTING SPIRAL BEVEL GEAR GENERATOR
| Maximum Diameter Gear | 17.7" | 449.58 mm |
| Maximum Face Width | 2.6" | 66.04 mm |
| Extreme Ratio | 10:1 | 10:1 |
| Control Manufacturer | Fanuc | Fanuc |
| Control | CNC (Fanuc 150MB) | CNC (Fanuc 150MB) |
| Dimensions | 188" x 134" x 100" | 188" x 134" x 100" |
| Weight | 24,156 | 24,156 |
Specifications:
Largest Speed Ratio: 10:01
Work Area (Continuous):
Largest Depth of Teeth: 15.24 mm
Largest Width of Tooth Face: 50.8 mm
Work Area Axis:
Horizontal Movement X Axis: -114 - 178 mm
Vertical Movement Y Axis: -178 - 190 mm
Movement of the Carriage Baseplate Z-Axis: -10.16 - 500 mm
Workpiece Headstock Swivelling Range B-Axis: -3 - 90 Degree
Maximum Distance Machine Center to Spindle Side: 165 mm
Number of Teeth: 5-200 Inclusive
Max. Gear Pitch Dia. of Typical 35 Deg. Spiral Angle Gear Using
Max. Cutter Dia. 12" Cutter at the Following Ratios:
Face Milling
1 x 1 - 13.5" - 342.9mm
2 x 1 - 16.0" - 406.4mm
5 x 1 - 17.7" - 450.0mm
Face Hobbing (210mm Dia. Cutter)
1 x 1 - 10.560" - 268.22mm
2 x 1 - 10.286" - 275.00mm
5 x 1 - 11.810" - 300.00mm
Milling Head Diameter:
Helixact: 100,125,169,200,250,320mm
Continuous Gumption Procedure, Teichloroethylene: 102 - 210 mm
Workpiece Spindle:
Drilling of Large Diameters: 5 3/64"
Cone Upward Gradient on 304.8 mm (1 Foot): 21/32"
Deep One of the Cone: 5.29"
Diameter of the Whole Spindle Perforating: 3.35"
Speeds:
B-Axle Workpiece Headstock Drag Axis: 30 Degrees
A-Axle Workpiece Spindle Number of Revolutions: 0 83 min-1
X-Axis Horizontal: 80 mm/sec
Y-Axis Vertically: 80 mm/sec
Z-Axis Carriage Baseplate: 80 mm/sec
Space Requirement L x W x H (Approx): 4.75 x 3.40 x 2.54m
188" x 134" x 100"
Machine Weight (approx): 10980 kg
24,156 lbs
Fanuc 150MB CNC Control
Dry Cutting
Cutter Shroud
Chip Evacuation System
Auto Doors
Hydraulic System
Lubrication System
Worklight
Stack Light
