| Guide | Spur | Spur |
| Maximum External Gear Diameter | 10" | 254 mm |
| Maximum Internal Gear Diameter | 10" | 254 mm |
| Diametral Pitch | 4 | 4 |
| Stroke | 2" | 50.8 mm |
| Control Manufacturer | Conventional | Conventional |
| Dimensions | 119" x 53" x 97" | 119" x 53" x 97" |
| Weight | 11,000# | 11,000# |
Specifications:
Strokes per Minute: 33 - 1300
Maximum Pitch Diameter (External): 10"
Maximum Pitch Diameter (Internal): 10"
Maximum Diametral Pitch (Spur): 4
Maximum Diametral Pitch (Helical): 5
Maximum Face Width 10-2: 2"
Maximum Helix Angle (Using 5" Cutter): 45 Deg
Maximum Overall Length: 118-7/8"
Maximum Overall Height (Zero Raise): 96-1/2
Maximum Overall Depth: 53"
Net Weight With Motors: 11,000 lbs
Tilt Table
3-Cut Cycle
Cutter Positioning
Coolant System
Fixture Clamping
Lube
Auto Cycle
Change Gears
Hydraulic System
Heat Exchanger
