The ROYAL MASTER TG12x4 is a used precision centerless grinder known for its exceptional accuracy and versatility in grinding small-diameter components. Designed for both infeed and thru-feed applications, this machine is widely used in industries requiring tight tolerances and fine surface finishes. Its compact footprint and robust design make it ideal for high-volume production environments. Currently located in New Jersey, this unit is available for immediate purchase and integration into grinding operations.
| Capacity | 1.5" | 38.1 mm |
| Grinding Wheel Dia. | 12" | 304.8 mm |
| GW Power | 7.5 hp | 5.6 kW |
| Regulating Wheel Dia | 6" | 152.4 mm |
| RW RPM | 500 RPM | 500 RPM |
| Weight | 999 lbs | 999 lbs |
EQUIPPED WITH:
AUTOMATIC CYCLE OPTION .... PROVIDES AUTOMATIC INFEED
OF THE REGULATING WHEEL
"PRECISION" REGULATING WHEEL SPINDLE
AIR SENSING CLOSE TOLERANCE HYDRAULIC DRESSER,
FOR THE GRINDING WHEEL
AIR SENSING CLOSE TOLERANCE HYDRAULIC DRESSER,
FOR THE THE REGULATING WHEEL
INFEED WORK REST WITH BLADES
PART EJECTOR
DIAL INDICATOR FOR REGULATING WHEEL MOVEMENT
DIGITAL OF THE REGULATING WHEEL SPEEDS
COOLANT SYSTEM, tank & pump
SELF CONTAINED HYDRAULIC SYSTEM
7.5 H.P. MAIN DRIVE MOTOR
3/60/208-230-460 VOLT ELECTRICS
WIRED PRESENTLY FOR 3/60/460 VOLTS
