| X-Axis | 30" | 762 mm |
| Y-Axis | 16" | 406.4 mm |
| Z-Axis | 20" | 508 mm |
| # Axis | 3 | 3 |
| Power | 20 hp | 14.9 kW |
| RPM | 8,100 RPM | 8,100 RPM |
| Taper | Cat 40 | Cat 40 |
| # ATC | 24 | 24 |
| Table-W | 36" | 914.4 mm |
| Table-L | 14" | 355.6 mm |
| Pallets? | No | No |
| 4th Axis | NO | NO |
| Control | CNC (HAAS) | CNC (HAAS) |
| Dimensions | 101" X 99" X 101" | 101" X 99" X 101" |
| Weight | 8,000 | 8,000 |
TRAVELS
-X AXIS: 30"
-Y AXIS: 16"
-Z AXIS: 20"
MAX TABLE LOAD: 3,000 LBS
SPINDLE MOTOR: 20 HP
SPINDLE SPEED: 8,100 RPM
SPINDLE TAPER: 40 CT
TOOL CHANGER: 24 ATC
MAX TORQUE: 90 FT-LBF
MAX TOOL DIAMETER: 3.5"
MAX TOOL WEIGHT: 12 LB
TOOL-TO-TOOL (AVG): 4.2 S
CHIP-TO-CHIP (AVG): 4.5 S
TABLE SIZE: 36" X 14"
DIMENSIONS: 101" X 99" X 101"
WEIGHT: 7,800 LBS
PROGRAMMABLE COOLANT
THROUGH SPINDLE COOLANT
24+ SIDE MOUNT TOOL CHANGER
INTERNAL HIGH VOLT TRANSFORMER
CHIP AUGER
