| Ton | 220 T | |
| Bed L-R | 55 in | |
| Bed F-B | 32 in | |
| Stroke | 7.88 in | |
| Shut Height | 17.73 in | |
| OBI Single Double | Single Crank | Single Crank |
Capacity: 220 Ton
Stroke: 7.88”
Adjustment: 4.33”
Die Height: 17.73”
Speed: 20 - 50 SPM
Bed Area: 55” lr x 32” fb
Slide Area: 33” lr x 24” fb
EQUIPPED WITH:
Air Clutch and Brake
Air Counterbalance
Motorized Slide Adjustment
Overall height: 12’6”
Catalog Weight: 46,000#
