TOYODA WELE AA956 CNC Vertical Machining Center, 2012 model. Specs: 43.3" x 25.6" table, 35.4" x 25.6" x 23.6" XYZ travel, 1980 lb load, CAT 40 taper, 8000 RPM, 20 ATC. Features FANUC OI-MD control.
| X | 35.4" | 899.16 mm |
| Y | 25.6" | 650.24 mm |
| Z | 23.6" | 599.44 mm |
| Power | 1,015 hp | 756.9 kW |
| RPM | 8,000 RPM | 8,000 RPM |
| # ATC | 20 | 20 |
| Taper | CAT 40 | CAT 40 |
| Table-W | 25.6" | 650.24 mm |
| Table-L | 43.3" | 1,099.8 mm |
TABLE SIZE ....................... 43.3" x 25.6"
X AXIS TRAVEL .................... 35.4" 900mm
Y AXIS TRAVEL .................... 25.6" 650mm
Z AXIS TRAVEL .................... 23.6" 600mm
MAXIMUM TABLE LOAD ............... 1980 LBS
SPINDLE TAPER .................... CAT 40
MAXIMUM SPEED SPEED .............. 8000 RPM
TOOL MAGAZINE CAPACITY ........... 20 ATC
RAPID TRAVERSE RATE .............. 988.8 IPM
SPINDLE NOSE TO TABLE............. 4.9" MIN TO 28.5" MAX
APPROX FLOOR SPACE REQUIRED ...... 116"L X 88"W X 115.7"H
MACHINE WEIGHT ................... 15,400 LBS
FANUC MODEL: OI-MD CONTROL
SET UP FOR RENISHAW PART PROBE
BOX WAYS
CHIP CONVEYOR
SIDE MOUNTED TOOL CHANGER
10/15 SPINDLE MOTOR
