Vertical Machining Center
Manufacturer: Fadal Engineering Company, Inc.
Model: VMC 4020HT (906-1)
Date of Manufacture: 1998
Electrics: 230-440 Volts, 3 Phase, 60 Cycle, 45-22.5 Amp
Features and Specifications:
...Control: Fadal CNC 88HS
...Table Size: 20″ x 48″
...Spindle Taper: CT40
...Max. Speed: 10,000 RPM
...Machine Travels (3-Axis):
......X-Axis: 40″
......Y-Axis: 20″
......Z-Axis: 28″
...Max Cutting Feed Rate: .01-250 IPM
...Rapid Traverse Rate:
......X/Y: 700 IPM
......Z: 600 IPM
...Spindle to Table Distance: 4″ – 32″
...Spindle Center to Column Distance: 20″
...ATC: 30 Stations
...Tool Changer: Horizontal Carousel
...Expanded Memory
Overall Dimensions (approx.): 100" x 98" x 110" Tall
Weight (approx.): 12,500 lbs.
Advertised specifications and functionality history is taken from 1st-hand inspection, owner interview, manuals, and OEM research. While specifications are assumed accurate, confirmation by purchasing entity is always recommended.
Functionality Notes and History:
The present owner is 2nd owner of this unit; he has had it around 15 years. Has never replaced the spindle; replaced the way lube when he purchased. Machine has been a good runner for him. He is selling machine to make room for some recently purchased equipment.
Machine is presently under power and doing production work. Some areas are blurred out in photos because current owner wanted to ensure his job setup was not compromised.
CALL FOR DETAILS, SCHEDULE INSPECTION
WE ARE OPEN TO OFFERS
EQUIPMENT LOCATION: Olympia, WA
Equipment is under power; available for inspection.
Buyer responsible for rigging and loading fees.
Buyer responsible for freight logistics and expenses.
Contact MD Equipment Services LLC to schedule inspection or arrange purchase details.
