.5" Cap, 5+1 Axes, Fanuc
| # Axis | 6 | 6 |
| X-Axis | 9" | 228.6 mm |
| Y-Axis | 7" | 177.8 mm |
| Z-Axis | 6" | 152.4 mm |
| A-Axis | 1-15 to 90 ° | 1-15 to 90 ° |
| B-Axis | -110 to 40 ° | -110 to 40 ° |
| C-Axis | 360 ° | 360 ° |
| Grinding Wheel Dia. | 5.91" | 150.11 mm |
| Wheelhead Angle | Up to 105° | Up to 105° |
| Power | 5.5 hp | 4.1 kW |
| Max RPM | 7,200 RPM | 7,200 RPM |
| Dimensions | 81.1" x 80" x 74.02" | 81.1" x 80" x 74.02" |
| Weight | 7,716 Lbs | 7,716 Lbs |
Part loader
