| X Axis | 192" | 4,876.8 mm |
| Y Axis | 180" | 4,572 mm |
| Z Axis | 72" | 1,828.8 mm |
| A-Axis | +/- 115° | +/- 115° |
| C-Axis Rotation | +517°/- 7° | +517°/- 7° |
| Distance Between Columns | 144" | 3,657.6 mm |
| Power | 40 hp | 29.8 kW |
| RPM | 20,000 RPM | 20,000 RPM |
| # ATC | 20 | 20 |
| Taper | HSK-63A | HSK-63A |
| Table-W | 144" | 3,657.6 mm |
| Table-L | 216" | 5,486.4 mm |
**Over $1 Million Replacement Cost**
Fanuc 310i-B5 Control
Dust/Chip Collection System
Rear Dust/Chip Enclosure
Through the Spindle Mist Coolant
Renishaw RCUIO
Renishaw RMP 600 Radio Frequency Inspection Probe System
