| X | 30" | 762 mm |
| Y | 20" | 508 mm |
| Z | 20" | 508 mm |
| # Axis | 5 | 5 |
| Power | 30 hp | 22.4 kW |
| RPM | 15,000 RPM | 15,000 RPM |
| # ATC | 40 | 40 |
| Taper | BT40 | BT40 |
| Table-W | 19.7" | 500.38 mm |
| Table-L | 24.8" | 629.92 mm |
| Control | CNC (Haas) | CNC (Haas) |
| Dimensions | L x W x H: 162" x 113" x 120" | L x W x H: 162" x 113" x 120" |
| Weight | 14,500 Lbs | 14,500 Lbs |
Specifications (subject to buyer verification):
X-Axis Travel: 30”
Y-Axis Travel: 20”
Z-Axis Travel: 20”
No. of Axis: 5
Power: 30 HP
Spindle Speed: 15,000 RPM
Spindle Nose to Platter: 4" - 24"
Table Width: 19.7”
Table Length: 24.8”
Travel: 360°
Max Speed: 150°/sec
Max Torque: 450 ft-lbs
Brake Torque: 3300 ft-lbs
Max Swing: 27"
Dimension L x W x H: 162" x 113" x 120"
Weight: 14,500 Lbs
Equipped With (subject to buyer verification):
W.I.P.S Wireless Probe System
300 PSI Thru Spindle Coolant
Chip Conveyor
Integrated 5-Axis Table
Rotation & Scaling
Rigid Tapping
M19 Spindle Orientation
High Speed Machining
Maximum Memory 32GB
