2003 MARVEL 2125A-PC60 20" x 25" Capacity at 90 degrees, Fully Automatic 60 degree vertical saw
FEATURES:
Bar feed system:
24" Shuttle stroke
Hydraulic index
Marvel PCII control
Feed rate control
Feed pressure control
Hydraulic blade feed system
Built in coolant system
Pan / sump and pump included
Pre-wired for mist lube system
Manual hand-crank style chip conveyor
Chip collection Included
| Work Height | 20" | 508 mm |
| Power | 5 hp | 3.7 kW |
| Blade Width | 1.25" | 31.75 mm |
| Blade Length | 210" | 5,334 mm |
| FPM | 30 - 650 FPM | 30 - 650 FPM |
| Control | CNC (MARVEL PCII) | CNC (MARVEL PCII) |
Cutting Capacity (Nominal): 20"x 25"
Cutting Capacity (45°): 20'x 17"
Cutting Capacity (60°): 20"x 11.25"
Round Capacity: 20"
Blade: 210"x 1.25"x .042"
Motor: 5HP blade drive
Guide Arm; Hydraulic, automatic clearing
Speed Range: 30 FPM - 650 FPM
Power Tilt: +/- 60°
Shuttle Pull: 24"Single, 1000" Multi-Cycle Max
Table Height: 38"
