Used 5-axis vertical machining center boasting a 24 hp spindle with 12,000 RPM and 40-tool ATC. Features include WinMax Control, coolant through spindle, and 550 lbs table load capacity. Weight: 15,752 lbs.
| X | 42" | 1,066.8 mm |
| Y | 24" | 609.6 mm |
| Z | 20.5" | 520.7 mm |
| # Axis | 5 | 5 |
| Power | 24 hp | 17.9 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 40 | 40 |
| Taper | CAT 40 | CAT 40 |
| Control | CNC (HURCO) | CNC (HURCO) |
| Dimensions | 179" x 148.5" x 117.75" | 179" x 148.5" x 117.75" |
| Weight | 15,752 lbs | 15,752 lbs |
Table Diameter 15.7"
Maximum Table Load 550 lbs.
X-Axis Travel 42.01
Y-Axis Travel 24.01
Z-Axis Travel 20.5"
A-Axis Travel -110 Degrees to +30 Degrees
C-Axis Rotation .001 Degree Increment Full 360 Rotation
Spindle Taper CAT 40
Spindle Speeds 12,000 RPM
Spindle Motor 24 HP
Maximum Spindle Torque 176.1 ft./lbs at 720 RPM
Distance Spindle Nose to Table Top 3.5" - 24"
Tool Magazine Capacity 40 Station Tool Changer
Maximum Tool Diameter / Length / Weight 3" / 11.8" / 15.4 lbs.
Rapid Traverse Rates X, Y / Z 1378 ipm, 1378 ipm / 1181 ipm
Cutting Feedrates 1260 IPM
Machine Dimensions LxWxH 179" x 148.5" x 117.75"
Machine Weight 15,752 lbs
Machine Control Hurco WinMax Control with Ultimotion
Simultaneous 5 Axis Capabilty
Coolant Through the Spindle
Renishaw RTS Contact Tool Probe and RMP600 Part Probe
Chip Conveyor
Centerline Probing
Mist Away Variable Speed Mist Collector
Flood Coolant System with Grundos Circulation Pump
Spindle Air Blast
Status Lights
Remote Jog Handle
Advanced Verification Graphic
Enhanced DXF File Transfer Ability
NC Productivity Package
Ultipockets
Insert Pockets
Rigid Tapping
Helical Ramp
NC Conversational Merge
