| Spindle Hole Dia | 32 mm | 1.2598" |
| Power | 23 kW | 30.8 hp |
| RPM | 7,000 RPM | 7,000 RPM |
| # Axis | 11 | 11 |
| Dimensions | 2,800 x 2,150 x 1790 | 2,800 x 2,150 x 1790 |
| Weight | 4,400kg | 4,400kg |
Number of axes : 11
Number of spindles : 2
Main Spindle Max. bar diameter : 1.25"
Main Spindle Max. machining length: 4.29"
Main Spindle Travel : 12.59"
Main Spindle speeds : 8000 [rpm]
Main Spindle power : 8 [kW]
Main Spindle C axis indexing precision : 0.001 [°]
Counter Spindle Max. bar diameter : 1.25"
Counter Spindle speeds : 8000 [rpm]
Counter Spindle power : 8 [kW]
Counter Spindle C axis indexing precision : 0.001 [°]
LOWER TURRET
- Number of positions : 10
- Number of motorized positions : 10
- X/Z stroke : 4.52"/ 4.72"
- Y stroke : 3.93"
- Live tools speed : 6000 [rpm]
- Live tools power : 1 [kW]
- Number of guide bush holders : 1
GUIDE BUSH HOLDER 1
- Number of positions : 9
- Number of motorized positions : 4
- Live tools speed : 6000 [rpm]
SECONDARY OPERATION
- Number of positions : 4
POWER SUPPLY
- Supply voltage : 400 [V]
- Total installed power : 40 [kW]
WEIGHT & DIMENSIONS
- Machine floor space : 141.7" x 86.6"
- Machine height : 70"
- Machine weight : 4600 [kg]
Siemens 840 D CNC Control,
3 colors status lamp,
Rotating guide bush,
Parts catcher,
Parts conveying strip,
Ejection of workpiece,
Chips conveyor,
Coolant tank,
high-pressure pump,
cooling unit for coolant,
Bar loader : FMB Turbo 3-36,
Oil mist extractor,
Cooling unit,
Fire extinguisher,
Koma Live Tooling Available,
