Working area
Center height: 5"
Workpiece length: 22"
Grinding length: 22"
Workpiece weight (max.): 8 lbs.
Grinding diameter: 8"
X axis travel: 6"
Z axis travel: 24"
Inside grinding diameter: 0.51 – 4"
Inside grinding depth: 5"
Max. table swivel range (r+l): 3° / 9°
Feed
Table feed, infinitely variable: 4 – 157 mm/min
Headstock
Work spindle speed, infinitely variable: 40 – 460 rpm
Headstock swivel range: 360° / 45° pitch
Work spindle taper: MT 4
Grinding Headstock
Grinding spindle speed: 1670 rpm
Inside grinding spindle speed: 15000 rpm
Grinding headstock swivel range (r+l): 30° / 180°
Tailstock
Tailstock taper: MT 4
Drive Capacities
Motor rating
- Work spindle: 1 HP
- Inside/Outside grinding: 5 HP
- X / Z axis feed: 1.7 / 1.7 HP
Total connected load: 11 kVA
Dimensions/Weight
Grinding wheel dimensions in 16 x 2 x 8"
Dimensions: 114 x 88 x 69"
Weight: 5952 lbs.
Part No. 100 018
Includes a few arbors for different ID wheel sizes.
Fagor 8055i FL-TCO Control,
Parts for this machine are still being manufactured and service is still provided by Knuth,
