Max. Chuck Size: 10"
Spindle Nose Size: A2-6
X-Axis Travel: 7.4"
Z-Axis Travel: 6.6"
Spindle Motor: 11kW
Spindle Speed: 2,000 RPM
Live Tool Speed: 3,000 RPM
Max. Live Tool Diameter: Milling-16mm, Tapping-M16
Rapid Rate X-Axis: 18m/min
Rapid Rate Z-Axis: 15 m/min
Control: Fanuc 31i-A
Cutting Time: 18,827 Hours
M/Z Weight: 4000 kg
Loader Wrkpx Wgt: 8kg x 2
Materials Cut: Aluminum Castings
8" Chuck,
Chip Conveyor,
3 Axis Gantry Robot Loader,
Turning / Milling / Drilling Capabilities in every Turret Position,
