CNC Router
| X | 4,200 mm | 165.35" |
| Y | 850 mm | 33.465" |
| Z | 650 mm | 25.591" |
| Power | 9.5 kW | 12.7 hp |
| RPM | 24,000 RPM | 24,000 RPM |
Make an Offer
Inquire Now Buy Now
Activate Pricing
Table Width: 25"
Table Length: 248"
X-Axis Travel: 247"
Y-Axis Travel: 25"
Z-Axis Travel: 9.8"
Number of Spindles: 1
Spindle Speed: 24,000 RPM
Spindle Motor: 15 HP
Max Machining Length with Profile End Machining: 6,280 mm
Max Machining Length without Profile End Machining: 6,400 mm
Tool Changer: 8 Station
Control: Windows Based OS
Software: EluCam
15" Color Displace: 4-Axis Profile Machining Center
USB Ports: Claping Unit to Accomodate Double Profile Machining
Drilling and Tapping Capabilities: Network Connection
