NEW LOCKFORMER PITTSBURGH LOCK 16

Overview
Manufacturer:
LOCKFORMER
Status:
For Sale
Description

The 14, 16 and 18 gauge Pittsburgh rollforming machines have 7 forming stations with two forming positions. One inboard position forms the Pittsburgh lock; and one auxiliary or outboard position has the capability of forming 1 of 8 different profiles depending on which auxiliary roll set is ordered.

The Pittsburgh lock revolutionized the HVAC industry in the late 1940’s and is still used today for its strength and ease in assembling ductwork. And for nearly that long, the Lockformer Pittsburgh Lock Roll Formers have set the standard for product quality and performance. The Lockformer Pittsburgh Lock Roll Former | Model 16 has a capacity of 16–20 gauge at a speed of up to 40-45 feet/minute and features seven (7) forming stations with two (2) forming positions — one inboard forming position forms the Pittsburgh lock and one auxiliary or outboard forming position has the capability of forming 1 of 8 different profiles depending on which auxiliary roll set is ordered.

Specifications
Number of Stands77
Power3 hp2.2 kW
Dimensions58.5"L x 24"W x 41"H58.5"L x 24"W x 41"H
Weight625 (LBS)625 (LBS)

SPECIFICATIONS

Model - Lockformer Pittsburgh Lock Roll Former | Model 16
Forming Stations - 5
Capacity - 16–20 gauge
Depth of Pocket - 1/2" Uses approximately 1-3/8" of material
Hammer Over-edge Adjustability - 3/8”
Forming Speed - 40–45 feet per minute

Motor - 3 hp, 230/460 volts, 60 cycle, 3 phase, A.C. 3,600 RPM. Other motors available upon request.

Dimensions - 58.5″L x 24″W x 41″H
Passline - 34”
Shipping Weight - 750 pounds

Equipped With

Additional Rolls

Pittsburgh Lock Rolls
Capacity - 22 - 28 gauge
Material Used - 1” (Approx)
Size - 5/16” Pocket

Double Seam Rolls (TYPE S)
Capacity - 22 - 28 gauge
Material Used - 1-1/8” (Approx)
Size - 3/8” Seam

Double Seam Rolls (TYPE L)
Capacity - 16 - 22 gauge
Material Used - 1-1/4” (Approx)
Size - 7/16” Seam

Drive Cleat Rolls
Capacity - 20 - 26 gauge
Material Used - 2-1/8” (Approx)
Size - 1-1/8” Width

Standing Seam Rolls
Capacity - 16 - 20 gauge
Material Used - 2-1/8” (Approx)
Size - 3/4” Height

Right Angle Flange Rolls
Capacity - 16 - 24 gauge
Material Used - Up to 7/16”
Size - Up to 7/16” Height

Hem Rolls
Capacity - 20 - 24 gauge
Material Used - 1/4”, 3/8”, 1/2” (Approx)
Size - 1/4”, 3/8”, 1/2”

COMBINATION 3 IN 1 ROLLS WITH SPECIAL GUIDE

Right Angle Flange
Capacity - 22 - 26 gauge
Material Used - 1/2” (Approx)
Size - 1/2” Height

Standing Seam
Capacity - 22 - 26 gauge
Material Used - 1-3/4” (Approx)
Size - 5/8” Seam

T-Connection
Capacity - 22 - 26 gauge
Material Used - 1-1/4” (Approx)
Size - 7/16” Seam

More Details:

Lockformer Pittsburgh Lock Roll Formers are available in six (6) different configurations (including the Model 16 shown) with varying capacities, configurations, and forming speeds to fit your specific operational needs. All Lockformer Pittsburgh Lock Roll Formers feature:

Industrial motors and high-precision needle-type bearings

Heavy 3/4″ chassis plate

Case-hardened and ground roll shafts

Arc-welded steel stands protected with Lockformer’s top-quality primer and paint finish.
