5 Axis CNC Router
| Table-W | 60" | 1,524 mm |
| Table-L | 120" | 3,048 mm |
| Power | 10 hp | 7.5 kW |
| # Axis | 5 | 5 |
Make an Offer
Inquire Now Buy Now
Activate Pricing
Number of Axis: 5
Table Width: 60"
Table Length: 120"
Number of Tables: 1
Table Hold Down: Aluminum Plate, Drilled & Tapped for Mounting Fixtures
Spindle Mfg: Colombo
Spindle Motor: 10 HP
Z-Axis Travel: 48"
Z - Clearance: 42"
Tool Changer: (8) Position Carousel Style Traveling ATC
Control: Fagor 8055
Power Requirement: 480v - 3 ph (Transformer reduction to 208 V, 3-phase)
AC inverter drive with spindle/machine run time indicator (10 HP): AC servo drives for all axes – Medium Duty
Full covers over ball screws: bearings and rails
Full machine documentation: Intelligent multifunction teach pendant for rapid part digitizing & programming
Operator podium for part program selection from loading position: Tool Holder Included
Trabon central lube system with low-level switch
