CNC Lathe
| Swing | 33" | 838.2 mm |
| Machining Length | 118" | 2,997.2 mm |
| Chuck Size | 15" | 381 mm |
| Bar Capacity | 10" | 254 mm |
| Max RPM | 2,400 RPM | 2,400 RPM |
| Turning Dia | 25.5" | 647.7 mm |
| Tailstock | Yes | Yes |
Make an Offer
Inquire Now Buy Now
Activate Pricing
Chuck Size: 15"
Bar Capacity: 10"
Swing: 33"
Turning Diameter: 25.5"
Spindle Speed: 2,400 RPM
Control: Okuma OSP CNC Control
Distance Between Centers: 118"
Turret: 12 Station
Chip Removal: Chip Conveyor
X-Axis Travel: 17.32/ 12.01’’
Z-Axis Travel: 121.65/119.09’’
Main Motor: 60 HP
Steadyrest: Tailstock Proggramable
Coolant System: Dual Turret
