CNC Horizontal Machining Center
| X | 20" | 508 mm |
| Y | 18" | 457.2 mm |
| Z | 14" | 355.6 mm |
| Power | 20 hp | 14.9 kW |
| RPM | 8,000 RPM | 8,000 RPM |
| # ATC | 24 | 24 |
| Pallet-W | 11.8" | 299.72 mm |
| Pallet-L | 11.8" | 299.72 mm |
Make an Offer
Inquire Now Buy Now
Activate Pricing
Pallet Size (Millimeters): 300
Pallet Size: 11.8" x 11.8"
X-Axis Travel: 20"
Y-Axis Travel: 18"
Z-Axis Travel: 14"
Tool Magazine Capacity: 40 ATC
Spindle Speed: 8,000 RPM
Spindle Taper: CAT 40
Control: Haas CNC
Pallet Indexing: Full 4th Axis
Chip Removal: Chip Conveyor
Coolant: Through Spindle Coolant
Probes: Remote Jog Handle
Rigid Tapping: Auxiliary Coolant Filter
