Machine is LIKE NEW, one of the best machines we have ever stocked! Current replacement cost over $925,000 with a 1 year wait. High horsepower, great for steel or exotics.
----------------------------------------------------------------------------------------
Space-saving design
— Machine height 134.4 in.
— Machine width×Machine depth 132.7×234.5 in.
— Customers can choose a magazine with the ideal number of tools to suit their needs, while keeping the machine width as it is
---
Direct Drive Motor of original technology
— The world’s fastest rotary axis drive system, which achieves zero backlash
— High-speed rotation and high-precision indexing
— Less maintenance and longer product life
---
DCG of original technology
— Longer tool life
— Improved surface quality and roundness
— Outstanding acceleration
----------------------------------------------------------------------------------------
Specifications:
-- Latest CNC Fanuc System 30/i5 Loaded with Options
-- X-Axis Travel: 41.34″ (extended)
-- Y-Axis Travel: 35.43″
-- Z-Axis Travel: 38.58
-- 120 Tools
-- Full Rotary Table
-- 10,000 RPM CAT 50 Taper High HP Spindle
-- Large High Pressure Cooljet System – 1,000 PSI
-- Renishaw Probe Included
-- 6 APC Pallet Changer
-- Operation Panel Type Slimline (15)
-- Customer Factory Voltage (V) 220 V
-- Cylindrical Interpolation Provided
-- Part Program Storage (Byte) 2 Mbyte (5120 M)
-- X-Axis Travel: 43.3″ Extended
-- User Memory Area(Built-In Mapps) 50 Mb
-- Spindle (Spindle 1) Output (Kw) Standard (15/11 Kw)
-- Tool Position Offset
-- Number Of Tool Offset Pairs 400
-- Spindle Hole Taper Taper #50
-- Number Of Work Coordinate System Pairs 48
-- Retention Knob Standard (#50) Special (Center-Through)
-- Arbitrary Angle Chamfer Corner R Command
-- Programmable Mirror Image
-- Chip Disposal Direction Left Disposal Type
-- Automatic Corner Override
-- Chip Conveyor Outside Machine
-- Number Of Custom Macro Common Variables 600
-- Type Of Chip Conveyor Outside Machine Drum / Scraper (Inner Pan Type/Dmg Mori)
-- Coordinate System Rotation
-- Through-Spindle Coolant System Discharge Pressure (MPA) 7.0 MPA
-- Polar Coordinate Commands
-- Shower Coolant System
-- Ai Contour Control 2
-- Tool Life Management A
-- In-Machine Work Measuring System (Spindle) Optical Type Probe Sensor (Renishaw) (Interface Only)
-- Mapps Tool Management System Without Tool IC Or Tool Id System
-- In-Machine Work Measuring System (Table) Table Mount Sensor (Renishaw) (Interface Only)
-- Mapps Mtconnect Adapter
-- Signal Light 4-Tier Tower (Red, Yellow, Green, Blue)
-- Stored Stroke Check 2,3
-- Additional Axis Interface 1 Additional Axis For Mori DDRT (External Type)
-- Ethernet/Ip
-- *All factory shipping brackets were installed by DMG MORI
