The Used 2017 DMG MORI NHX4000 GEN 2 is a robust and precision-engineered horizontal machining center designed to deliver high productivity in a compact footprint. Renowned for its superior performance in multitasking applications, this second-generation model features advanced automation, thermal compensation, and high-speed spindle capabilities. Ideal for complex machining operations in a production setting, the NHX4000 GEN 2 combines DMG MORI’s industry-leading build quality with user-friendly controls and efficient chip management systems to ensure reliable operation and consistent output across a wide range of materials.
| # Axis | 4 | 4 |
| Pallet-L | 15.7" | 398.78 mm |
| Pallet-W | 15.7" | 398.78 mm |
| X-axis Travel | 22" | 558.8 mm |
| Y-axis Travel | 22" | 558.8 mm |
| Z-axis Travel | 26" | 660.4 mm |
| Rapid Traverse Rate (X/Y/Z) | 2362 ipm | 2362 ipm |
| Spindle Speed | 12,000 RPM | 12,000 RPM |
| Spindle Taper | CAT-40 | CAT-40 |
| Spindle Motor | 15 hp | 11.2 kW |
| # ATC | 60 | 60 |
| Weight | 18700 | 18700 |
CNC Control
Chip Conveyor
