Machine is in Excellent Condition & Ready For Inspection.
| Swing | 60" | 1,524 mm |
| Dimensions | 123”L x 116”W x 104”H | 123”L x 116”W x 104”H |
| Weight | 20,000 Lbs | 20,000 Lbs |
Specifications:
Model - T60
Year - 1953
Swing - 60”
Chuck Diameter - 54”
Carriage Travel - 50”
Compound Travel - 16”
Distance From Chuck To Compound - 4” to 20.5”
Spindle Bore - 11.5”
Spindle Speeds - 6 to 338 RPM
Feeds - 1 to 65 TPR
Main Motor - 20 HP
Electrics - 220V/440V/3PH/60HZ
Made In - USA
Approximate Weight - 20,000 LBS
Approximate Overall Dimensions - 123”L x 116”W x 104”H
Equipped With:
Four Jaw Chuck
Double Tool Post
Four Post Tool Holder
Push Buttons
