Technical data
Min. grinding diameter 0.1 mm
Max. grinding diameter 10 mm
Width of the grinding wheel 50 mm
Grinding wheel:
diameter new wheel 150 mm
Width 50 mm
Bore 50 mm
Speeds:
up to 6000 rpm
Regulating spindle:
diameter new wheel 100 mm
Width 50 mm
Bore 40 mm
Speeds:
stepless
from 15 rpm
up to 150 rpm
Main motor 2.0 HP
Machine's weight about 650 kg
Overall dimensions machine:
Length 1800 mm
Width 1400 mm
Height 1600 mm
Various accessories:
Paper filtration system
Technical specifications without guarantee.
Technical data
Min. grinding diameter 0.1 mm
Max. grinding diameter 10 mm
Width of the grinding wheel 50 mm
Grinding wheel:
diameter new wheel 150 mm
Width 50 mm
Bore 50 mm
Speeds:
up to 6000 rpm
Regulating spindle:
diameter new wheel 100 mm
Width 50 mm
Bore 40 mm
Speeds:
stepless
from 15 rpm
up to 150 rpm
Main motor 2.0 HP
Machine's weight about 650 kg
Overall dimensions machine:
Length 1800 mm
Width 1400 mm
Height 1600 mm
Various accessories:
Paper filtration system
Technical specifications and pictures without guarantee.
