B-24 Arter Surface Grinder, 30" Chuck Capacity, 24" Chuck, 10 HP Spindle Motor, Neutrofier II Controls, Attached Electrical
Chuck Size | 24" | 609.6 mm |
Size Capacity | 30" | 30" |
Horz/Vert | Horz | Horz |
Power | 10 hp | 7.5 kW |
Swing | 34" | 863.6 mm |
Under Wheel | 8" | 203.2 mm |
Grinding Wheel Width | 2" | 50.8 mm |
Grinding Wheel Dia. | 20" | 508 mm |
Dimensions | 96 x 87 | 96 x 87 |
Weight | 9500 | 9500 |
ARTER B-24/30" ROTARY SURFACE GRINDER
S/N 935
STANDARD SPECIFICATIONS
Capacity...............................................30"
Surface diameter of magnetic chuck.....................30"
Greatest swing inside water pan........................34"
Vertical capacity full diameter wheel..................8"
Tilt of work table for convex grinding.................10°
Tilt of work table for concave grinding................10°
Diameter of grinding wheel – 12" hole..................20"
Width of grinding wheel................................2"
Wheel spindle..........................................950 RPM
Wheel spindle drive motor 1800 – 1500 Rpm..............3 HP
Hydraulic drive motor 1200 – 1000 Rpm..................7 1/2 HP
Net weight.............................................9500
Crated weight..........................................10,000
Boxed weight...........................................11,300
Cubic feet – boxed.....................................370
Floor space occupied...................................96" x 87"
EQUIPMENT & FEATURES
Neutrofier II controls.
24” Chuck.
10 HP Spindle motor.
12” OD x 2” wide wheel.
Electromatic chuck controls.
Attached electrical.
Specifications are deemed accurate, however, subject to verification or prior sale.
